High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine

Name: High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine
Brand: ETON
Price: 1 USD

Brand Name : ETON

Model Number : HT-E8S-1200

Certification : CE,SIRA,CCC,ISO

Place of Origin : SHENZHEN,CHINA

MOQ : 1 set

Price : EXW USD 48000/sets

Payment Terms : T/T, L/C

Supply Ability : 50 sets per mouth

Delivery Time : 30 days after deposit

Packaging Details : Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.

name : pick and place machine

System : Windows7

Total weight : 1250kg

Nozzles : 8PCS

Speed : 40000CPH

PCB size : 1200*350mm

Dimension : 2550*1650*1550mm

Camera : 2 sets of imported camera

Contact Now

High Accuracy led bulb assembly IC smd making machine pick and place machine

Product details
1. Precision mounting head system
The mounting method of 8 nozzle heads, group picking and separate placing / separate picking and separate placing can meet the mounting requirements of different components.
Each nozzle head is independently controlled by an independent servo motor to reduce feeding and ensure mounting accuracy at a higher speed than the stepper motor.
2. High precision imported screw
The X and Y axis adopts high-end magnetic linear motor to control the screw, and the Z axis adopts panasonic servo motor to control and drive, with ultra-high acceleration performance and stable movement speed to ensure the accuracy and stability of each step of mounting.

Scope of application
Lamps and lanterns: fluorescent lamp, bulb lamp, ceiling light, panel light, cast light lamp, mining lamp, down light, etc
Lighting: soft light tube, hard tube, advertising module, etc
Pasting class: LED watch pasting

HT-E8S
PCB	PCB length width	Max:1200300mm min:100100mm
	PCB thickness	0.5~5mm
	PCB clamping	Adjustable pressure pneumatic
	Mounting mode	ØGroup to picking and separate to placing ØSeparate to picking and separate to placing
O.S.	system	Windows 7
	software	R&D independently
	display	Touch screen monitor
	Input device	Keyboard , mouse
Vision system	No.of camera	2sets of imported camera Vision for the alignment identification,mark correction
	Mounting precision	0.02mm(repeat precision)
	Mounting height	<36mm
	Mounting speed	40000CPH
	Components space	0.2mm
	No.of feeders station	30PCS
	No.of nozzles	8PCS
	Power	380AC 50HZ
	Power consumption	4KW
	Conveyor transmission	Max length:1200mm
	Transmission speed	>500mm/sec
	Transmission direction	Both direction
	Transmission mode	Auto online drive
	Air pressure	>5.0kg /cm²
	Electrical control	Independent research and development by ETON
	Motion control card module 1set	Independent research and development by ETON
	X,Y,X axis drive way	Servo motor control for X,Y,Z axis
	Feeding way	Electric feeder with double motor

Company information
Shenzhen Eton Automation Equipment co., LTD. is a professional manufacturer of pick and place machine. Our company independently research, development, design and manufacturer a set of high -speed good quality SMT pick and place machine. And we received a number of patents issued by the state certificate and support. Nowadays, we have served many factories and enjoyed good reputation.

High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine

High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine

Honour show
ETON advanced technology and innovation drives the revolution of market rapidly ,and obtains a number of intellectual property technologies.
Including 9 invention patents,112practical patents,12 software copyrights.
High Accuracy Smt Pick Place Machine Led Bulb Assembly Ic Smd Making Machine

Logistics and delivery
Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
Our packing is made of wooden box with vacuum package, and we promise to deliver the goods within four weeks after payment.

FAQ:
1.How many cameras does the machine have?
There are two sets of imported cameras.Using exclusive patent technology:vision for the flight identification,Mark correction.
2.What is the direction of transmission of machines?
The transmission direction of this machine is both direction.
3. What kind of driving mode does the XYZ axis adopt?
X axis is magnetic liner motor,Y axis and Z axis is servo motor,very good performance and high accuracy.
4. What is the mounting mode?
Group to picking and separate to placing,Separate to picking and separate to placing.
5.Is your software interface in English?
English interface and Chinese interface are both available.
